| Item No. | MI125M | |
| U/Price (FOB Chongqing, China) | US$ 1,280.00 | |
| Certificate | Euro 3 | |
| 1 | ENGINE | 4 Strokes, Air-Cooled |
| 2 | Cylinder | Single, Ceremic Coated |
| 3 | Bore x Stroke | 56.5mm x 49.5mm |
| 4 | Displacement (cc) | 124 |
| 5 | Compression Ratio | 10:01 |
| 6 | Valve Train | SOHC |
| 7 | Max Power (hp/rpm) | 11/8500 |
| 8 | Max Torque (N.m./rpm) | 9/7500 |
| 9 | Lubrication System | Forced and Wet Sump |
| 10 | Fuel Grade | Unleaded |
| 11 | Clutch | Wet Type and Multi-Plates |
| 12 | Transmission | 5 speed gear Change |
| 13 | Gear Shift Pattern | 1-N-2-3-4-5 |
| 14 | Ignition System | C.D.I. |
| 15 | Starter System | Electric Start |
| 16 | Main Frame | 13A Multi Twin Spar |
| ¡¡ | ¡¡ | Trellis Configuration |
| 17 | Rear Swing-Arm | T6 Aluminum Trellis |
| ¡¡ | ¡¡ | with Forged Dropout |
| 18 | Out-Riggers | T6 Aluminum Trellis Forged |
| ¡¡ | ¡¡ | Twin Plate Bearing Carrier |
| 19 | Yokes | T6 Aluminum Forged |
| 20 | Front Suspension | Conventional |
| 21 | Rear Shock | Fast Ace |
| 22 | Seat High (mm) | 800 |
| 23 | Wheel Base (mm) | 1350 |
| 24 | Front Rim | Aluminum 2.75¡Á17 |
| 25 | Rear Rim | Aluminum 3.50¡Á17 |
| 26 | Front Tire | CST 100/70-17 |
| 27 | Rear Tire | CST 130/70-17 |
| 28 | Final Drive | Cushioned |
| 29 | Net Weight (kg) | 115 |
| 30 | Speedometer | Koso Digital and Mechanical |
| Option Parts: | ||
| 1 | Remote Control: | $10.00 |
